BACK GROOVING MACHINES
MJS2000-L
Back Grooving Machine
Chain belt feeding for panel back grooving, with a maximum feeding width of 2000 mm.
Feeding Width(mm)Max.:2000; Min.:300
Working Length(mm)50-350
Manufactured by OMAC R&D, manufacturing, sales & service Discuss your configuration with our team
Get a quote for MJS2000-L Have a specific material or application? Let’s discuss it. THE DETAILS THAT MATTERKnow your
Know your
next machine.
Review the technical specifications and talk to OMAC about the configuration that suits your production.
Ask about this machineTechnical specifications MJS2000-L
| Feeding Width(mm) | Max.:2000; Min.:300 |
|---|---|
| Working Length(mm) | 50-350 |
| Working Thickness(mm) | Max.25; Min.:5 |
| Spindle Diameter(mm) | 80 |
| Spindle Speed(r/min) | 2600 |
| Saw Blade Diameter(mm) | 180 |
| Power of Spindle Motor(kw) | 22KW or 30KW |
| Power of Feeding Motor(kw) | 2.2KW or 3KW |
| Feeding Mode | Chain belt feeding |
| Overall dimensions(mm) | 2650 x 2100 x 1100 |
| Weight (kg) | 2200 |
Specifications are based on the OMAC product catalog. Please confirm the required configuration and operating conditions with OMAC before ordering.
